Technical Specifications
| BRAND | Dell |
|---|---|
| STORAGE FAMILY | PowerVault |
| SERVER MODEL | MD1200 |
| FORM FACTOR | 2U Rack |
| NO.OF DRIVES | Up to Fifteen (15) LFF SAS or SATA hot-pluggable HDDs |
| DRIVE EFFICIENCY AND CAPACITY | 15K RPM SAS drives available in 600GB, 450GB, 300GB, 146GB, , and 73GB 10K RPM SAS drives available in 600GB, 400GB, and 300GB Nearline SAS (7.2K RPM) drives available in 1TB, 750GB, or 500GB 7.2K RPM SATA II drives available in 2TB, , 1TB, 750GB, 500GB, and 250GB |
| MAX STORAGE | 30TB (15 x 2TB ) |
| MAX EXPANSION CAPACITY | Upto 3 Enclosures |
| RAID CONFIGURATION | PERC 5/E, RAID levels: RAID 0, RAID 1, RAID 5, RAID 10, RAID 50 PERC 6/E, RAID levels: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| POWER SUPPLY | 478W (Max continuous); 550W (peak) |
| DIMENSIONS (H X W X D) | 13.11 cm x 44.63 cm x 48.01cm |
| (EMM) ENCLOSURE MANAGEMENT MODULES | 1 or 2 EMM |
